Idler Pivot w/Gusset Kit

More Views

Idler Pivot w/Gusset Kit


Part# IPAWG8

$209.00

Idler Pivot w/Gusset Kit
209 In Stock
Description

Details

2001 - 2010 GM 8-Lug Idler Pivot Assembly with Weld in Gusset
For the GM 01-10 8-Lug vehicles, including the 1500HD, 2500, 2500HD, 3500, 2500 Suburban/YukonXL/Avalanche, and Hummer H2.


The Cognito Motorsports pitman idler arm support kit takes care of the issues with the centerlink side of the pitman and idler arms. There is however another weak link in the front IFS steering on the 6 and 8lug GM vehicles. The idler pivot assembly tends to wear out, bend, and even break under stress with as little as 35” tires. The idler pivot assembly is what the idler arm is mounted to, and pivots on.

Cognito offers an aftermarket idler pivot assembly in order to strengthen your weak stock parts. The aftermarket Idler Pivot assembly has tapered roller bearings, adding strength and durability, thus creating a solid pivot point for your steering components. It doesn’t stop there. The idler pivot assembly mounting tabs tend to twist or even dislodge from the frame. Included with the kit is a weld in gusset in order to strengthen the weak factory mounting tabs. This kit is highly recommended, even more important than adding our heavy duty heim jointed tie rods.

Play in the idler pivot can cause major tie rod issues. If the idler pivot assembly has an issue, the idler arm is able to move uncontrollably. As this happens you will have drastic tie rod angle changes. In certain instances a bent or failed part can cause complete disaster to your front end. Some damages may include: idler arm rubbing the transmission oil cooler lines or motor mount, pitman arm, idler arm, and tie rod breakage. Most tie rod problems stem from worn or damaged pitman and idler arms or idler pivot assembly. View Installation instructions here.

Product Data

Additional Information

Component Description: No
Height x Length x Width (DIM) 9x9x5
Product Data:

 Click Here for Installation Instructions.
Manufacturer Cognito Motorsports
Please choose your option: No
Product Notes: No
Product Requires: No
Ship Via: FedEx
Weight 7.0000
Product Video N/A
Product Video Description N/A
Shipping Price: N/A
Los Banos California93635US
